Metal Waterproof Cable Gland
Metal Waterproof Cable Gland
Category: Products
Category: Waterproof cable glands
E-mail: bangtai@188.com
+86-020-86443644
400-7777-188
- Product
-
- Commodity name: Metal Waterproof Cable Gland
Metal Waterproof Cable Gland
Product number thread size Bayonet range Thread outer diameter Screw Tail Length Packaging (only/bag) RQM-PG7 PG7 3～6 12.5 6.0 100 RQM-PG9 PG9 4～8 15.2 6.0 100 RQM-PG11 PG11 6～10 18.6 7.0 50 RQM-PG13.5 PG13.5 8～12 20.4 8.0 50 RQM-PG16 PG16 10～14 22.5 8.0 50 RQM-PG21 PG21 13～18 28.3 9.0 20 RQM-PG29 PG29 18～25 37.0 10.0 10 RQM-PG36 PG36 25～32 47.0 11.0 10 RQM-PG42 PG42 32～38 54.0 11.0 10 RQM-PG48 PG48 37～44 59.3 11.0 10 RQM-M8×1.25 M8×1.25 3～5 8.0 6.0 100 RQM-M10×1.5 M10×1.5 3～7 10.0 6.0 100 RQM-M12×1.5 M12×1.5 3～7 12.0 6.0 100 RQM-M14×1.5 M14×1.5 3～7 14.0 6.0 100 RQM-M16×1.5 M16×1.5 4～8 16.0 7.0 100 RQM-M18×1.5 M18×1.5 6～10 18.0 7.0 100 RQM-M20×1.5 M20×1.5 8～12 20.0 8.0 50 RQM-M22×1.5 M22×1.5 10～14 22.0 8.0 50 RQM-M24×1.5 M24×1.5 10～14 24.0 8.0 50 RQM-M25×1.5 M25×1.5 10～14 25.0 8.0 50 RQM-M27×1.5/2.0 M27×1.5/2.0 13～18 27.0 8.0 50 RQM-M30×1.5/2.0 M30×1.5/2.0 13～18 30.0 8.0 50 RQM-M32×1.5/2.0 M32×1.5/2.0 15～22 32.0 9.0 20 RQM-M33×1.5/2.0 M33×1.5/2.0 15～22 33.0 9.0 20 RQM-M36×1.5/2.0 M36×1.5/2.0 18～25 36.0 9.0 20 RQM-M37×1.5/2.0 M37×1.5/2.0 18～25 37.0 9.0 20 RQM-M40×1.5/2.0 M40×1.5/2.0 22～28 40.0 10.0 20 RQM-M42×1.5/2.0 M42×1.5/2.0 22～28 42.0 10.0 10 RQM-M48×1.5/2.0 M48×1.5/2.0 25～32 48.0 10.0 10 RQM-M50×1.5/2.0 M50×1.5/2.0 25～32 50.0 10.0 10 RQM-M54×1.5/2.0 M54×1.5/2.0 32～38 54.0 12.0 10 RQM-M56×1.5/2.0 M56×1.5/2.0 32～38 56.0 12.0 10 RQM-M60×1.5/2.0 M60×1.5/2.0 37～44 60.0 12.0 5 RQM-M63×1.5/2.0 M63×1.5/2.0 37～44 60.0 12.0 5 RQM-M64×1.5/2.0 M64×1.5/2.0 37～44 64.0 12.0 5 RQM-M72×1.5/2.0 M72×1.5/2.0 42～52 72.0 15.0 5 RQM-M75×1.5/2.0 M75×1.5/2.0 42～52 75.0 15.0 1 RQM-M76×1.5/2.0 M76×1.5/2.0 42～52 76.0 15.0 1 RQM-M80×1.5/2.0 M80×1.5/2.0 50～62 80.0 16.0 1 RQM-M85×1.5/2.0 M85×1.5/2.0 60～70 85.0 18.0 1 RQM-M88×1.5/2.0 M88×1.5/2.0 60～70 88.0 18.0 1 RQM-M90×1.5/2.0 M90×1.5/2.0 60～70 90.0 18.0 1 RQM-M100×1.5 M100×1.5/2.0 70～80 100.0 20.0 1 RQM-G1/4 G1/4" 3～7 13.2 6.0 100 RQM-G3/8 G3/8" 4～8 16.7 7.0 100 RQM-G1/2 G1/2" 8～12 20.9 8.0 50 RQM-G3/4 G3/4" 13～18 26.4 8.0 20 RQM-G1 G1" 15～22 33.2 9.0 20 RQM-G1-1/4 G1-1/4" 22～28 41.9 10.0 10 RQM-G1-1/2 G1-1/2" 25～32 47.8 10.0 10 RQM-G2 G2" 37～44 59.7 12.0 10 RQM-G2-1/2 G2-1/2" 42～52 75.2 15.0 1 RQM-G3 G3" 65～70 87.9 18.0 1
Keywords: Metal Waterproof Cable Gland
Related Products
Material: Nylon
Working temperature: -30～+90℃
Environmental protection certification: ROHS, REACH, halogen-free
Flame retardant properties: V2;
Material properties:
Strong locking force, better toughness and tensile strength, chemically stable, resistant to alkali and most chemical solvents, resistant to inorganic salts, mineral oil, easy to absorb water;
Material:Nylon
Operating temperature:-40～+100℃;
Certification：ROHS；
Material properties：
Excellent resistance to high and low temperature, high mechanical strength, chemical stability, alkali solution and most chemical solvents, inorganic salt, mineral oil, easy water absorption;
Material: Zinc alloy、NBR
Operating temperature:-40～+100℃;
Certification：ROHS；
product feature
Corrosion resistance, lock fastness, convenient disassembly and assembly;
Material:Nylon
Operating temperature:-40～+100℃;
Certification：ROHS；
Material properties：
Excellent resistance to high and low temperature, high mechanical strength, chemical stability, alkali solution and most chemical solvents, inorganic salt, mineral oil, easy water absorption;
